DVB-T/DTMB Antennas HOME >> Product >> DVB-T/DTMB Antennas

Shenzhen SD Communication Equipment Co., Ltd-4K Full HD Active Square Thin Film antenna

DVB-T/DTMB Antennas

4K Full HD Active Square Thin Film antenna

ShenZhen Shengda Communication Equipment Co., Ltd. specializes in microwave, mobile, satellite communications antennas and related communications products R & D, production and sales of high-tech enterprises, is the early development and production of communication antennas, one of the professional manufacturers. The company has advanced antenna testing instruments and automatic antenna far-field testing system, a variety of products won the domestic new products and quality Products Award, Science and Technology Progress Award.

 4K Full HD Active Square Thin Film antenna  Product Details




Application & Feature:

  • This antenna is designed for indoor DVB-T /DVB-T2 ATSC ISDB-T application etc.

  • 4K and FULL FREE HD CHANNELS-- Cut monthly cable and get access to local news, weather, sitcoms, kids and sports, educational programs etc.

  • The 50-80 mile HDTV Antenna lets you enjoy over-the-air networks in your area without paying a monthly fee.

  • HD CRYSTAL CLEAR TV SHOW-- Please first visit "antennaweb.org" or "antennapoint.com" to check how many broadcast towers surrounding you within 50-80 miles.

  • Enjoy crystal clear HDTV shows, 720p, 1080i, 1080p | ATSC available.

  • HDTV antenna pulls in hundreds of crystal clear digital & HD shows!

  • Receives free HD channels including ABC, CBS, NBC, PBS, Fox, Univision and more.

  • It has detachable amplifier

Specification:

Electrical indicators Electrical Specifications

Frequency Range

VHF170-240MHz/UHF470-860MHz


Gain

30dbi


Polarization

verticalvertical


VSWR

Or less2.0


Maximum input power

50W


Input impedance

75Ω


Interface form

FJ


Lightning Protection

The dc groundingMaximum input power


Mechanical properties Mechanical Specification

type

Type

Indoor TV antenna

The antenna size

Dimensions of Antenna

250*223*0.6mm

The weight of the

weight

0.14Kg

cable

Cable

RG17475Ω,L=5Plus or minus0.03M

Working temperature

Working temperature

- 40°~ + 60°

Suitable for indoor DVB-T / DVB-T2 application




US or EU Standard charger





This antenna has high gain, wide frequency band, interference resistance


✿Before purchasing our antenna please visit https://www.tablotv.com/tools/ to make sure you have stations within range.
You can only receive channels within the 75 mile radius and mountainous and heavily treed areas will reduce the range considerably.
1) Connect the coaxial cable on the antenna to the amplifier.
2) Place the antenna, preferably on a window or as high as possible.
3) Connect the HDMI cable from the amplifier to the TV.
4) Go to input on your TV and make sure it is set for TV

5) Go to the menu on your TV and make sure it is set for "air" or "antenna", whichever you TV menu has.
6) In the menu on your TV go to "Scan for Channels" or "Channel Scan" etc., select "ok" and scan. This may take up to 20 minutes to complete.

✿Troubleshooting tips:

1) If after scanning for channels you do not receive any channels move the antenna to a different location and do another channel scan.
2) Make sure your input is set to TV
3) Check all connections
If after doing all the above correctly and you are still unable to receive channels, Please email us.



Our Services

1. Superior Quality
Our QC ensures do everything they can for quality checking .
We inspect all incoming material before they are put on the production line and warehouse, so all our      customer no need worry about the quality problem.

2. Faster Response/Delivery
Customer service available on working time (8 : 30 – 17 : 30) from Monday to Saturday. Well-trained staff will arrange Orders/Sample by courier, such as DHL, UPS and FedEx, TT average of 7 days, 2~4 weeks finish sea shipment, shipments are insured for successful delivery and trackable online.

3. Professional, Value for money
We are directly manufacturer, OEM&ODM , any customized antenna we can design and make it to product. Better price than trading company.

Delivery time: 7 working days on receipt of sample payment
15 working days on receipt of order payment proof

Quality is essential for both of us, we believe that High quality, Low price,Mutual benefit will be the basic of our cooperation.
