4G LTE Antennas HOME >> Product >> 4G LTE Antennas

4G LTE Antennas

4G full-band suction cup antenna

ShenZhen Shengda Communication Equipment Co., Ltd. specializes in microwave, mobile, satellite communications antennas and related communications products R & D, production and sales of high-tech enterprises, is the early development and production of communication antennas, one of the professional manufacturers. The company has advanced antenna testing instruments and automatic antenna far-field testing system, a variety of products won the domestic new products and quality Products Award, Science and Technology Progress Award.

 4G full-band suction cup antenna Product Details

Electrical properties ELECTRICAL
Type of Model	SD-LTE0727Z090
The Frequency Range of Frequency Range	700-960/1710-2700-MHz
Bandwidth Bandwidth	260/990-MHz
Gain Gain	3dBi
Pattern voltage standing wave ratio VSWR	2.0 or less
Polarization mode Polarization	Perpendicular to the Vertical
Maximum work rate of the main Max power	50 -W
The input Impedance of Nominal Impedance	50 -Ω

The mechanical parameters MECHANICAL
Joint type Connector	SMAMale head or customer specified SMA male or customized
The Antenna size can Antenna Dimension be used	90mm
The Weight of the Weight	36g
Color Color	Black, Black 3 m
The Wind strength Rated Wind Velocity	60-m/s

Previous product：LTE 4G high gain chuck antenna

Next Product：4G copper rod suction cup antenna 2.5 m SMA male

Advanced antenna test instrument

The company has a strong design team, and the product quality is improving year by year,
The production process is constantly updated to make the product more perfect.
The frequency of the product ranges from 30MHz to 6GHz, and the microwave antenna can be developed according to user requirements.

Shenzhen SD Communication Equipment Co., Ltd

Strong Production Strength

STRONG PRODUCTION STRENGTH

The company's independent research and development, independent production, independent sales, to customers the most transparent price! The leading products are base station plate antennas, GPS antennas, digital TV antennas, etc. The frequency of the company's products ranges from 30MHz to 6GHz.

Shenzhen SD Communication Equipment Co., Ltd优势

Strict Quality Assurance

STRICT QUALITY ASSURANCE

The company's supporting production has advanced production testing equipment, network analyzer, spectrum analyzer, comprehensive instrument, salt spray tester and other imported testing equipment. The company has passed ISO9001 quality system certification and ISO14001 environmental system certification.

Strong Technicalrdc Team

STRONG TECHNICALRDC TEAM

The SD team is almost dedicated to the pursuit of product technology, based on customer product characteristics, technical improvement design of the product, supplemented by scientific lean manufacturing, so that SD products quickly laid a good foundation with its excellent quality and excellent service. prestige.

SD A Good After-sales Service

SD A GOOD AFTER-SALES SERVICE

The professional technical service team of Tsingda Communication Equipment has rich experience and excellent technical service in time, which has become a solid backing for winning the market. We will, as always, follow the business philosophy of “Quality First, Customer First”.
